Round Oled 0 . 75 inch PMOLED display module white monochrome with IC SSD1327Z

OKP-128128-04,0.75 inch Round OLED Display Features:

1. Diagonal Screen Size: 0.75"
2. Interface: I2C, 4-wire SPI
3. Number of Pixels: 128x128
4. Control/drive IC: SSD1327
5. Display: White Oled
6. Pins: 15
7. Color: Monochrome (White )
8. Power Supply Voltage: 2.6-3.5V
9. Brightness: 80(Min) cd/m2
10. Internal DC/DC Enable:
11. Supplied Externally: 14V
12. Folding Ability: Folding Type
13. Assembly: Soldering

Mechanical data:
Outline: 23.15x 25.93x1.02mm
Active area: D=19.18 mm
Dot Pitch: 0.15×0.15mm
Operating Temperature (°C): -30--70
Storage Temperature (°C): -40--80

FAQ:

1. Q:Can you provide technical assistance?
A: Yes,We can provide technical support on software and hardware.
2. Q: Does your product have any warranty?
A:Yes, we offer 3 months warranty for our products. Damage due to misuse, ill treatment and unauthorized modifications and repairs are not covered by our warranty.
3. Q: Can we guarantee long-term supply?
A: Yes,Strong factory guarantee long-term supply.
4. Q: Do you offer custom solution?
A: Yes,we can offer custom solution if standard products couldn't meet buyer' requirements.
